MIL-PRF-40136K
used in intimate contact unless protected against galvanic corrosion. The materials of the tanks
and pump unit shall be compatible with all types of motor gas, diesel fuel, and aviation fuel.
3.7.6.3 Cleaning, treatment, and painting. All surfaces, normally painted shall be cleaned,
treated, and painted in accordance with the manufacturer's standard commercial practice. Special
color, pattern, or requirements shall be specified in contract or order (see 6.2).
4. VERIFICATIONS
4.1 Classification of inspections. Inspections are classified as follows:
a. First article inspection (see 4.2).
b. Conformance inspection (see 4.3).
4.2 First article inspection. When specified (see 6.2) a first article inspection shall be
performed on a complete unit(s). This inspection shall include the examination of 4.4 and the
tests of 4.5.
4.3 Conformance inspection. Production unit inspection shall include examination of 4.4 and
the testing of 4.5.9.1.
4.4 Examination. Each unit shall be physically examined for compliance with the
requirements indicated by an "X" in Table II. This element of inspection shall encompass all
examinations of performance, safety, human engineering, and dimensional requirements. Non-
compliance with any specified requirement, or the presence of one or more defects lessening
required efficiency shall constitute cause for rejection.
TABLE II. Examinations.
Item
Type
Type
Examination
Reference
Method of
I
II
paragraph
examination
101
X
Type I tanks and pump unit physical
3.3.1
Visual/Doc.
characteristics not as specified.
102
X
Type II tank and pump unit physical
3.3.2
Visual/Doc.
characteristics not as specified
103
X
X
Tank not as specified.
3.3.3
Visual/Doc./SIE
104
X
X
Bottom loading valve not as
3.3.4
Visual/Doc./SIE
specified.
105
X
Fuel sensor cutoff not as specified.
3.3.5
Visual/Doc.
106
X
X
Tank access not as specified.
3.3.6
Visual/SIE
107
X
X
Manifold not as specified.
3.3.7
Visual/Doc.
108
X
Pump unit not as specified.
3.3.8
Visual/Doc.
109
X
X
Lifting provisions not as specified.
3.6.1
Visual/Doc.
110
X
X
Tiedown/mounting provisions not as
3.6.2
Visual/Doc./SIE
specified.
111
X
X
Maintainability not as specified.
3.7.1
Visual/SIE
9
